High output with top quality
Hybrid is a new developed technology which use hydraulics but instead without proportional valve.
Hybrid brakes are becoming more prevalent and more widely available.
There is a mix of electric and hydraulic systems that allow the machine to be much more responsive while maintaining a higher degree of accuracy than a traditional hydraulic press brake system.
Over the years, manufacturers have been developing different solutions to improve the performance of their products. Through tools, functionalities and technological innovations sheet metal press brakes have evolved starting from mechanical presses to hybrid cnc press brakes. Hybrid is a new developed technology which use hydraulics but instead without proportional valve. Hybrid Brakes are becoming more prevalent and more widely available. With a servo-hydraulic drive, when you turn the pump on each cylinder in one direction, you are pumping the ram down, when the cnc control unit sets the pump in the other direction, you are pumping the ram back up. By controlling the speed of the servo, you can also control the ram speed.
Benefits of this technology include substantial power saving as you don’t have a conventional AC motor running all or most the time. The servos only activate as required. You also get incredibly fast response time and minimal piping as it does away with a central tank and proportional valves. You can expect higher speeds for both high-speed approach and high-speed return, around 200mm/sec. Hybrid press brakes use hydraulics in small tanks to assist with bending process and servo motors to control the flow to the cylinders. Small oil tanks translate into many advantages, such as:
Moveable and adjustable support arms — A range of support arms for light- and heavy-duty- sheet metal-work
Extremely stable backgauge — Servo driven (Fast) and CNC controlled (Stable) multiple backgauge configurations from 2 to 6 axis
Motorized guard system — Easily openable door with remote control
